Car Monitor Installation Explained

One of the most important things that you will need to contemplate before even attempting to install a regular car DVD monitor, or perform a challenging headrest monitor install, is what type of tools will be required for the job. Even though each vehicle and each car monitor system is different there are still some fundamental items you will most likely need to successfully complete the car monitor installation process. The majority of projects you will require needle nose pliers, a flat head screwdriver, a Philips-head screwdriver, and a combination wire crimp and strip tool. Other tools to consider are a panel tool, utility knife, ratchet/socket set, drill/bit set and a torque driver set as well. Keep in mind that this is only a short list of the more basic tools that are needed and numerous other tools may also be needed as you proceed with your install job.

BR-V Fuel Lid Cover Image, BR-V Photos in India - CarWale

Firstly, you need to begin by thoroughly reading the instructions and make sure to study any schematics supplied with the car DVD monitor to make sure you completely understand the whole process of successfully installing it properly.

Even though there are many makes and models of car DVD monitors on the market, they are still usually composed of 3 essential components. These include the DVD player itself, the LCD or TFT monitor, and the audio system. Furthermore, you will need to understand that there are 4 main different types of installations that will cause you to experience 4 varying degrees of difficulty Maxisys Elite.

They are as follows:

2 DIN Car Monitor System

The term ‘DIN’ is actually an internationally accepted standard for in-dash car multimedia units. The number 2 in front of the DIN basically means that it is a standard double deck slot size.

This particular type of system is mounted into the dashboard of a vehicle and will most likely make it slightly more difficult to install, especially if you are attempting to do it from scratch. Since a double DIN car monitor system contains the largest and most aesthetically pleasing screen for your entertainment needs it is probably worth all the effort.

2DIN car monitors, for the most part, are composed of a flat screen and a built-in DVD player. They also have an amplifier built right into the dashboard unit as well. You may discover that more unit mounts and connectors are required to get the car monitor to be seated in its slot snugly. Installation of this popular style of system needs a lot of re-wiring. If the outer edges of the monitor are too large or too small for a non-standard stereo slot then you may have to perform a custom resizing or remodelling of the dash to make sure the unit fits properly without any problems. A good rule of thumb is to double or even triple check the dimensions of your dashboard slot before even buying a brand new car monitor to install. This way you do not waste time or money.

In the process of your car monitor install you will most likely have to run wires from the head unit all the way to the individual speakers in the front, side and rear of your vehicle. All other secondary input devices, such as backup cameras or Bluetooth kits, will also require this. A crucial thing you must account for is to make sure that you are not running a wire to both ends of the emergency break cable since it is considered to be illegal in most countries to be able to operate the monitor when the car is in motion. The only exception to this rule would be that you are running a rear view camera while reversing your car. A final note is that you will also need to wire the car monitor player to the power supply of your vehicle.

1 DIN Car Monitor System

This particular type of car monitor is very much akin to the 2 DIN since it is also mounted into a dashboard and is necessitates a great deal of wiring to have it installed correctly. Be that as it may, the 1DIN car monitor player only takes up ½ of the needed space of a 2DIN unit. Even though it sounds easier to attempt this type of car monitor installation you may need to customize the slot size in the dash to make sure it fits tightly into its designated spot. Similar to the 2 DIN car monitor system it is made up of a color TFT or LCD screen, DVD player and amplifier. All the connections, mounting brackets, and wiring are definitely required but may not always be included by the manufacturer in your purchase.

Alternative Design Car Monitors

This class of car monitors is much less difficult to install than the 1or 2 DIN monitors but it will still pose you with some unique issues. While it is true that you do not need to fit the new electrical components to existing parts of the vehicle you are still required to perform a significant amount of wiring and rewiring to make sure the system is properly hooked up to an adequate power supply and stereo system to maximize your mobile multimedia experience. This type of car monitors installation you will require screws, wires, and adhesive.

For a headrest monitor install you will need to detach the fitted headrest from the seat and run power and connection wires down through the hole. The majority of cars or trucks should allow you to remove the cover off the bottom of the seat and put an unwound clothes hanger up through the slot to locate the cable and pull it out. After that you can run the wire under the carpet to the main head unit in the dashboard or directly to another connection box in another spot in your car.

Other unique car monitors, such as a sun visor DVD monitor or overhead car DVD monitor, will require you to consider other important factors such as how to fix the player to the ceiling of your car and how to wire the DVD monitor so that the cables cannot be seen by the passengers. When mounting the roof monitor you will need to install it in the center of the vehicle for maximum strength. Then you will need to conceal the wires beneath the ceiling panels by running them from the head unit to the dash or power supply. As you can see, this may require a lot of work as some panels and maybe even the seatbelt will have to be removed. Sun visor DVD monitors are not as hard to mount since the wires do not have to be extended too far to be attached to the power source or main adaptor. But they will still need some careful attention when removing and re-attaching car panels.
